Arduino Firefighter Robot
Arduino Firefighter Robot is a medium N/A recipe that serves 1.
Prep: 1 hr 45 min | Cook: 1 hr 35 min | Total: 3 hrs 35 min
Cost: $65.00 total, $65.00 per serving
Ingredients
- 1 piece Arduino Uno R3 (Microcontroller board)
- 2 pcs Servo motor (SG90) (For wheel movement)
- 2 pcs DC motor with wheels (Drive wheels)
- 1 pcs Miniature water pump (For fire suppression)
- 1 pcs IR flame sensor (Detects fire)
- 20 pcs Jumper wires (male‑to‑male) (For prototyping connections)
- 1 pcs Breadboard (Prototype wiring platform)
- 1 set 9V battery and connector (Power supply for the robot)
- 5 pcs Resistors (220Ω) (For LED indicators)
- 2 pcs Red LED (Indicates fire detection)
Instructions
Gather Components
Collect all listed components and verify you have the correct quantities before starting.
Time: PT15M
Assemble Chassis
Mount the DC motors with wheels onto the robot frame using screws; ensure the wheels rotate freely.
Time: PT30M
Wire Servo Motors
Place the breadboard on the chassis and connect the two SG90 servos to the Arduino’s PWM pins using jumper wires.
Time: PT20M
Connect Flame Sensor
Insert the IR flame sensor into the breadboard and wire its VCC, GND, and analog output to the Arduino (e.g., A0).
Time: PT10M
Wire Water Pump via Driver
Connect the water pump to a transistor driver circuit, then link the driver’s control pin to a digital output on the Arduino.
Time: PT15M
Solder Permanent Connections
Solder all breadboard connections onto a perfboard for durability, ensuring solid joints and proper insulation.
Time: PT30M
Temperature: 350°C
Program and Upload Code
Write Arduino code that reads the flame sensor, lights the LEDs when fire is detected, drives the servos for movement, and activates the pump; upload via the computer.
Time: PT45M
Test Fire‑Suppression Function
Place a small candle under the robot, power it on, and observe if the sensor triggers the LEDs and water pump correctly.
Time: PT20M
Final Adjustments and Secure Components
Trim excess wires, secure the perfboard and battery with hot glue, and ensure the pump nozzle is aimed forward.
Time: PT15M
Cleanup and Storage
Turn off power, unplug the USB, clean the work area, and store unused components in a dry box.
Time: PT15M
